Product Summary

The cm600du-24nf is a high power switching use Misubishi IGBT module. Applications of the cm600du-24nf include: General purpose inverters & Servo controls, etc.

Parametrics

cm600du-24nf absolute maximum ratings: (1) Collector-emitter voltage VCES: 1200V (G-E short) ; (2) Gate-emitter voltage VGES: ±20V (C-E short) ; (3) Collector current IC: 600A (DC, TC=111°C) ; (4) ICM: 1200A (Pulse) ; (5) Emitter current IE: 600A; (6) IEM: 1200A (Pulse) ; (7) Maximum collector dissipation: 2080W (Tc=25°C) ; (8) Junction temperature Tj: -40 to +150°C; (9) Storage temperature Tstg: -40 to +125°C; (10) Isolation voltage Viso: 2500V (Main Terminal to base plate, AC 1 min.) .

Features

cm600du-24nf features: (1) IC: 600A; (2) VCES: 1200V; (3) Insulated type; (4) 2-elements in a pack.

Diagrams

cm600du-24nf Circuit Diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
CM600DU-24NF
CM600DU-24NF

IGBT MOD DUAL 1200V 600A NF SER
Data Sheet
0-1: $252.81
1-10: $243.45
10-100: $234.08
100-250: $230.34
250-500: $224.72
CM600DU-24NFH
CM600DU-24NFH

IGBT MOD DUAL 1200V 600A NFH SER
Data Sheet
0-1: $218.22
