QM75DY-H

Mitsubishi transistor module, 70A, 600V, QM75DY-H, 350W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $33.00~38.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	38.00 / Piece
11 ~ 30 :	33.00 / Piece

PartNumber:: QM75DY-H

Brand:: MITSUBISHI - MITSUBISHI | D/C: 11+

Availability:: Supply Ability: 3/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. winny's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-22

From Other Seller

Part Number:QM75DY-H
US $33.00 - 38.00
QM75DY-H

US $50.00 - 50.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The QM75DY-H is a Mitsubishi transistor module. The applications of QM75DY-H are: Inverters, Servo drives, UPS, DC motor controllers, NC equipment, Welders.

Parametrics

QM75DY-H absolute maximum ratings: (1)VCEX (SUS) Collector-emitter voltage IC=1A, VEB=2V: 600V; (2)VCEX Collector-emitter voltage VEB=2V: 600V; (3)VCBO Collector-base voltage: 600V; (4)VEBO Emitter-base voltage: 7V; (5)IC Collector current: 75A; (6)–IC Collector reverse current: DC(forward diode current): 75A; (7)PC Collector dissipation TC=25℃: 350W; (8)IB Base current DC: 4.5A; (9)–ICSM Surge collector reverse current(forward diode current): 750A; (10)Tj Junction temperature: –40~+150 ℃; (11)Tstg Storage temperature: –40~+125 ℃; (12)Viso Isolation voltage: 2500V.

Features

QM75DY-H features: (1)IC Collector current: 75A; (2)VCEX Collector-emitter voltage: 600V; (3)hFE DC current gain: 75; (4)Insulated Type; (5)UL Recognized.
