CM200HA-24H

CM200HA-24H, Single IGBT Module, 1200V, 200A, 1500W, MITSUBISHI

Rated 5 Rating 5 | reviews | Write a review

Price:: US $28.00~33.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	33.00 / Piece
11 ~ 20 :	28.00 / Piece

PartNumber:: CM200HA-24H

Brand:: MITSUBISHI - MITSUBISHI | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. winny's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-05

From Other Seller

Part Number:CM200HA-24H
US $28.00 - 33.00
CM200HA-24H

US $15.00 - 15.00 / Piece
(0) Remove
IGBT MODULES HIGH POWER SWITCHING USE CM200HA-24H

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The CM200HA-24H is a 1200V (VCES), 200 Ampere Single IGBT Module. It is designed for use in switching applications. The CM200HA-24H consists of one IGBT in a single configuration with a reverseconnected super-fast recovery free-wheel diode. All components and interconnects are isolated from the heat sinking baseplate, offering simplified system assembly and thermal management.

Parametrics

CM200HA-24H absolute maximum ratings: (1)Junction Temperature, Tj: -40 to 150℃; (2)Storage Temperature, Tstg: -40 to 125 ℃; (3)Collector-Emitter Voltage (G-E SHORT), VCES: 1200 Volts; (4)Gate-Emitter Voltage (C-E SHORT), VGES: ±20 Volts; (5)Collector Current (Tc = 25℃), IC: 200 Amperes; (6)Peak Collector Current (Tj ≤ 150℃), ICM: 400Amperes; (7)Emitter Current (Tc = 25℃), IE: 200 Amperes; (8)Peak Emitter Current, IEM: 400 Amperes; (9)Maximum Collector Dissipation (Tc = 25℃), Pc: 1500 Watts; (10)Mounting Torque, M6 Main Terminal: 1.96~2.94 Nm; (11)Mounting Torque, M6 Mounting: 1.96~2.94 Nm; (12)Mounting Torque, M4 Terminal: 0.98~1.47 Nm; (13)Weight:400 Grams; (14)Isolation Voltage (Main Terminal to Baseplate, AC 1 min.), Viso: 2500 Vrms.

Features

CM200HA-24H features: (1)low drive power; (2)low VCE(sat); (3)discrete super-fast recovery free-wheel diode; (4)high frequency operation; (5)isolated baseplate for easy heat sinking.
