IRL1404ZS

HEXFET power MOSFET, 40V, 160A, D2PAK, 0.004Ω, IRL1404ZS, International Rectifier

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.80~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.20 / Piece
101 ~ 300 :	0.80 / Piece

PartNumber:: IRL1404ZS

Brand:: International Rectifier - IR | Pack: TO | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. winny's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-10

From Other Seller

Part Number:IRL1404ZS
US $0.80 - 1.20
Quantity:

piece

Product Summary

The IRL1404ZS is a HEXFET power MOSFET. It utilizes advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that the IRL1404ZS well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The D2Pak is a surface mount power package capable of accommodating die sizes up to HEX-4. The IRL1404ZS provides the highest power capability and the lowest possible onresistance in any existing surface mount package. The device is suitable for high current applications because of its low internal connection resistance and can dissipate up to 2.0W in a typical surface mount application.

Parametrics

IRL1404ZS absolute maximum ratings: (1)ID @ TC = 25℃ Continuous Drain Current, VGS @ 10V: 160 A; (2)ID @ TC = 100℃ Continuous Drain Current, VGS @ 10V: 110 A; (3)IDM Pulsed Drain Current: 640 A; (4)PD @TA = 25℃ Power Dissipation: 3.8 W; (5)PD @TC = 25℃ Power Dissipation: 200 W; (6)Linear Derating Factor: 1.3 W/℃; (7)VGS Gate-to-Source Voltage: ±20 V; (8)EAS Single Pulse Avalanche Energy: 520 mJ; (9)IAR Avalanche Current: 95 A; (10)EAR Repetitive Avalanche Energy: 20 mJ; (11)dv/dt Peak Diode Recovery dv/dt: 5.0 V/ns; (12)TJ Operating Junction and TSTG Storage Temperature Range: -55 to + 175 ℃.

Features

IRL1404ZS features: (1)Advanced Process Technology; (2)Ultra Low On-Resistance; (3)Dynamic dv/dt Rating; (4)175℃ Operating Temperature; (5)Fast Switching; (6)Fully Avalanche Rated.
