Product Summary
The ct15sm-24 is a Mitsubishi insulated gate bipolar transistor. Applications of the ct15sm-24 include: AC & DC motor controls, General purpose inverters, UPS, Power supply switching, Servo controls, etc.
Parametrics
ct15sm-24 absolute maximum ratings: (1) Collector-emitter breakdown voltage V(BR) CES: 1200V (IC=1mA, CGE=0V) ; (2) Collector-emitter leakage current IGES: ±0.5μA (VGE=±30V, VCE=0V) ; (3) Gate-emitter leakage current ICES: 1mA (VCE=1200V, VGE=0V) ; (4) Gate-emitter threshold voltage VGE (th) : 4.5 to 7.5V (IC=1.5mA, VCE=10V) ; (5) Collector-emitter saturation voltage VCE (sat) : 2.7 to 3.6V (IC=15A, VGE=15V) ; (6) Input capacitance Cies: 1600pF (VCE=25V, VGE=0V, f=1MHz) ; (7) Thermal resistance Rth (j-c) : 0.50°C/W (Junction to case) .
Features
ct15sm-24 features: (1) VCES: 1200V; (2) IC: 15A; (3) High speed switching; (4) low VCE saturation voltage.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CT15SM-24 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||
