Product Summary

The 2SA1268 is a PNP silicon epitaxial planar transistor. The is subdivided into two groups, G and L according to its DC current gain.

Parametrics

2SA1268 absolute maximum ratings: (1) Collector Base Voltage -VCBO: 120V; (2) Collector Emitter Voltage -VCEO: 120V; (3) Emitter Base Voltage -VEBO: 5V; (4) Collector Current -Ic: 100mA; (5) Emitter Current IE: 100mA: (6) Power Dissipation Ptot: 300mW; (7) Junction Temperature Tj: 125°C; (8) Storage Temperature Range Ts: -55 to +125°C.
