Product Summary
The mcd162-16io1 is a thristor/diode module. Applications of the mcd162-16io1 include: Motor control, Power converter, Heat and temperature control for industrial furnaces and chemical processes, Lighting control and Contactless switches.
Parametrics
mcd162-16io1 absolute maximum ratings: (1) ITRMB, IFRMB: 300A (Tvj=Tvjm) ; (2) ITAVM, IFAVM: 190A (Tc=80°C, 180°sine) , 181A (Tc=85°C; 180° sine) ; (3) ITSM, IFSM: 6000A (Tvj=45°C, t=10ms (50Hz) , sine, 6400A (VR=0, t=8.3ms (60Hz) , sine) ; (4) di/dt) er: 150A/μs (Tvj=Tvjm, f=50Hz, tp=200μs, VD=2/3 VDRM) , 500A/μs (IG=0.5A, diG/dt=0.5A/μs) ; (5) PGM: 120W (TVJ=TVJM, tp=30μs) , 60W (IT=ITAVM, tp=500μs) ; (6) PGAC: 8W; (7) VRGM: 10V; (8) TVJ: -40 to +125°C; (8) TVJM: 125°C; (9) Tstg: -40 to +125°C.
Features
mcd162-16io1 features: (1) International standard package; (2) Direct copper bonded Al2O3-ceramic base plate; (3) Planar passivated chips; 94) Isolation voltage 3600V; (4) UL registered, E 72873; (5) Keyed gate/cathode twin pins.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 MCD162-16io1 |
Ixys |
Discrete Semiconductor Modules 162 Amps 1600V |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
MCD132-14io1 |
Ixys |
Discrete Semiconductor Modules 132 Amps 1400V |
Data Sheet |
Negotiable |
|
||||
|
MCD132-16io1 |
Ixys |
Discrete Semiconductor Modules 132 Amps 1600V |
Data Sheet |
Negotiable |
|
||||
|
MCD161-20io1 |
Ixys |
Discrete Semiconductor Modules 161 Amps 2000V |
Data Sheet |
Negotiable |
|
||||
|
MCD162-08io1 |
Ixys |
Discrete Semiconductor Modules 162 Amps 800V |
Data Sheet |
Negotiable |
|
||||
|
MCD162-12io1 |
Ixys |
Discrete Semiconductor Modules 162 Amps 1200V |
Data Sheet |
Negotiable |
|
||||
|
MCD162-14io1 |
Ixys |
Discrete Semiconductor Modules STANDARD SCR 1400V, 162A |
Data Sheet |
Negotiable |
|
||||
