FF200R17KE3

C-series module, 1700V, 400A, 1250W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $38.00~43.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	43.00 / Piece
11 ~ 20 :	38.00 / Piece

PartNumber:: FF200R17KE3

Brand:: Infineon Technologies AG - Infineon | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. winny's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-04

From Other Seller

Part Number:FF200R17KE3
US $38.00 - 43.00
Quantity:

piece

Product Summary

The ff200r17ke3 is a 62mm C-series module with trench/fieldstop IGBT and EmCon diode.

Parametrics

ff200r17ke3 absolute maximum ratings: (1) collector-emitter voltage VCES: 1700V (Tvj=25°C) ; (2) DC-collector current IC nom: 390A (Tc=25°C) ; (3) repetitive collector current ICRM: 400A (tp=1ms, Tc=80°C) ; (4) total power dissipation Ptot: 1250W (Tc=25°C, Transistor) ; (5) gate-emitter peak voltage VGES: ±20V; (6) DC forward current IF: 200A; (7) repetitive peak forw. current IFRM: 400A; (8) insulation test voltage Visol: 3.4kV (RMS, f=50Hz, t=1 min.) .

Features

ff200r17ke3 features: (1) collector-emitter saturation voltage VCE sat: 2 to 2.45V (IC=200A, VGE=15V, Tvj=25°C) , 2.4V (IC=200A, VGE=15V, Tvj=125°C) ; (2) gate thresold voltage VGEtn: 5.2 to 6.4V (Ic=8mA, VCE=VGE, Tvj=25°C) ; (3) input capacitance Cies: 17nF (f=1MHZ, Tvj=25°C, VCE=25V, VGE=0V) ; (4) collector-emitter cut-off current VCE=1700V, VGE=0V, Tvj=125°C, ICES: 5mA; (5) gate-emitter leakage current VCE=0V, VGE=20V, Tvj=25°C, IGES: 400nA.
