Product Summary

The 6di50m-050 is a power transistor module. Applications of the 6di50m-050 include: general purpose inverter, uninterruptible power supply, servo&spindle drive for NC machine tools and robotics (servo drive for robots) .

Parametrics

6di50m-050 absolute maximum ratings: (1) VCBO: 600V; (2) VCEO: 600V; (3) VCEO (SUS) : 450V; (4) VEBO: 10V; (5) IC: 50A (DC), ICP: 100A (1ms) , -IC: 50A (DC) , IB: 3A (DC) , IBP: 6A (1ms) ; (4) Pc: 310W (one transistor) , Pc: 1860W (six transistors) ; (5) Tj: +150°C; (6) Tstg: -40 to +125°C; (7) Visol: 2500V.

Features

6di50m-050 features: (1) high DC current gain; (2) high speed swtiching.

Diagrams

6DI50M-050 Circuit
