Product Summary

The 2SA1266 is a silicon PNP transistor. Applications of the 2SA1266 include: low frequency amplifer and low nosie amplifer.

Parametrics

2SA1266 absolute maximum ratings: (1) Collector-base voltage VCBO: -50V; (2) Collector-emitter voltage VCEO: -50V; (3) Emitter-base voltage VEBO: -5V; (4) Collector current Ic: -150mA; (5) Emitter Current IE: 150mA; (6) Collector Power Dissipation Pc: 400mW; (7) Junction Temperature Tj: 125°C; (8) Storage temperature range Tstg: -55 to 125°C.

Features

2SA1266 features: (1) excellent hFE Linearity , hFE (0.1mA) / hFE (2mA) =0.95 (Typ.) ; (2) Excellent safe operation; (3) Low noise 2SA1266 NF=1 dB (TYP) , 10dB (Max) ; (4) Complementary to the 2SC3198.

Diagrams

2SA1266 Dimension
